12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M

12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M

  • 12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M
  • 12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M
  • 12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M
  • 12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M
12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M
Thông tin chi tiết sản phẩm:
Place of Origin: Shenzhen,China
Hàng hiệu: RAYTOP
Chứng nhận: CE, RoHS, FCC
Model Number: ET1200200
Thanh toán:
Minimum Order Quantity: 2K
Giá bán: Negotiable
Packaging Details: PE Bag, Master Carton, Customer package available.
Delivery Time: 15-20 work days.
Payment Terms: T/T, L/C
Supply Ability: 200,000 Pcs monthly.
Tiếp xúc
Chi tiết sản phẩm
AC Cable: 1.2M Application: Telephones, Printer
Approval: CE, RoHS, FCC, UL, SAA Cable Material: Copper
DC Cable: 1.2M EMI Standards: FCC Part 15 Class B
Feature: Constant Current Frequency: 50Hz / 60Hz
Input: AC100-240V Operating Temperature: 0~40℃
Output: 12V Plug: EU, US, UK, SAA, CCC
Product Name: wall mount power supply Protection: Short Circuit, Over Voltage, Over Current
Điểm nổi bật:

ac to dc power converter

,

wall plug adapter



12V 200mA Wall Mount Power Supply FCC Certified For Telephones , 1.2M





Quick Detail:



Switching mode power adapter, DC12V 200mA, in conformity with CE, RoHS, FCC certification, plug in power adapter.





Specs:



Input: AC100-240V, 1.2A max.

Frequency: 50/60Hz

Output: DC12V, 200mA

DC Cable: 24AWG, Copper, length: 1.2M

Plug: EU, UK, US, SAA, CCC





Features:



-High efficiency:>85%;

-Protection: Short circuit protection, over voltage protection, over current protection.

-MTBF: 50,000 hours.





Approval: CE, RoHS, FCC

Warranty: 2 years





Description:



This is an universal AC adapter come with single output tip 5.5x2.1x10mm. It has high efficiency as well as steady performance. The tip size and plug type can be changeable.





Note:



Indoor use only.





Applications:



widely used for electronic clock, small appliance, dust cleaner, game machine, security equipment etc.





Specifications:



Input

Rated Input Voltage

AC100~240V

Input Voltage Range

AC 90~264V

Rated Frequency

50/60 Hz

Input Frequency Range

47~63 Hz

Input AC Current

0.2A

Inrush Current

30A

Output

Rated Output Voltage

DC12V

Rated Output Current

200mA

Rated Power

3W

Ripple and Noise

150mV p-p

Standby Power Consumption

0.3W

Turn-on

5s

Hold-up

20s

Over Voltage Protection

Yes

Over Current Protection

Yes

Short Circuit Protection

Yes, automatically recover after short circuit removed.

Reliability

Hi-pot

3000Vac

Insulation Resistance

Input to output at 500Vdc

Leakage Current

5mA

EMI Standards

FCC Part 15B Class B

RoHS Compliant

Yes

MTBF

50,000 hours

Burn-in

40+/-5 ℃, full load, 12 hours

Drop Test

6 direction, each one time from height 1.0M

Environmental

Operating Temperature

0~40℃

Operating Humidity

10~80%

Storage Temperature

-20~65℃

Storage Humidity

0~90%

Safety Approvals

CE, RoHS, FCC, UL, SAA

Warranty

2 Years





Competitive Advantage:



-Open private model w/o extra cost for you;

-0.3% free backup of order quantity;

-Direct factory price without middle man.

-High performance-to-price ratio;

-Perfect after-sale service
