| Place of Origin: | Shenzhen,China |
| Hàng hiệu: | RAYTOP |
| Chứng nhận: | CE, RoHS, FCC |
| Model Number: | RT-WMA-0500100 |
| Minimum Order Quantity: | 100 PCS |
|---|---|
| Giá bán: | Negotiable |
| Packaging Details: | PE Bag, Master Carton, Customer package available. |
| Delivery Time: | 15-20 working days. |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 200,000 Pcs monthly. |
| Product Name: | 5V 1A Wall mount Power Adapter | Input: | AC10-240V, 50/60Hz, 0.3A |
|---|---|---|---|
| Output: | 5V, 1A / 6V 1A, 12V 0.5A | AC Plug: | EU,US,UK,SAA,CCC |
| AC Cable: | 2x0.5mm2, 1.2M | DC Plug: | AWG24, 1.2M |
| DC Connector: | 5.5x2.1mm, 5.5x2.5mm | Color: | Black |
| Protection: | Short circuit protection, over voltage protection, over load protection | ||
| Điểm nổi bật: | Wall Mount Power Supply,ac to dc power converter |
||
Quick Detail:
High frequency switching mode power adapter, DC 5V 1000mA, wall mount style in conformity with CE, RoHS, FCC certification
Specs:
Input: AC100-240V, 0.2A max.
Frequency: 50/60Hz
Output: DC5V, 1000mA
DC Cable: 24AWG, Copper, length: 1.2M
Plug: EU, UK, US, SAA, CCC
Features:
-World wide voltage input;
-High efficiency:>85%;
-Protection: Short circuit protection, over voltage protection, over current protection.
-MTBF: 50,000 hours.
Approval: CE, RoHS, FCC
Warranty: 2 years
Description:
This is an AC power adapter come with single output tip 5.5x2.1x10mm. It has high efficiency as well as steady performance. The tip size and plug type can be changeable.
Note:
indoor use only.
Applications:
used for digital devices, LCD, LED, emergency light, home appliance electrical products etc.
Specifications:
|
Input |
Rated Input Voltage |
AC100~240V |
|
Input Voltage Range |
AC 90~264V |
|
|
Rated Frequency |
50/60 Hz |
|
|
Input Frequency Range |
47~63 Hz |
|
|
Input AC Current |
0.2A |
|
|
Inrush Current |
30A |
|
|
Output |
Rated Output Voltage |
DC5V |
|
Rated Output Current |
1000mA |
|
|
Rated Power |
5W |
|
|
Ripple and Noise |
150mV p-p |
|
|
Standby Power Consumption |
0.3W |
|
|
Turn-on |
5s |
|
|
Hold-up |
20s |
|
|
Over Voltage Protection |
Yes |
|
|
Over Current Protection |
Yes |
|
|
Short Circuit Protection |
Yes, automatically recover after short circuit removed. |
|
|
Reliability |
Hi-pot |
3000Vac |
|
Insulation Resistance |
Input to output at 500Vdc |
|
|
Leakage Current |
5mA |
|
|
EMI Standards |
FCC Part 15B Class B |
|
|
RoHS Compliant |
Yes |
|
|
MTBF |
50,000 hours |
|
|
Burn-in |
40+/-5 ℃, full load, 12 hours |
|
|
Drop Test |
6 direction, each one time from height 1.0M |
|
|
Environmental |
Operating Temperature |
0~40℃ |
|
Operating Humidity |
10~80% |
|
|
Storage Temperature |
-20~65℃ |
|
|
Storage Humidity |
0~90% |
|
|
Safety Approvals |
CE, RoHS, FCC, UL, SAA |
|
|
Warranty |
2 Years |
|
Competitive Advantage:
-Open private model w/o extra cost for you;
-0.3% free backup of order quantity;
-Direct factory price without middle man.
-High performance-to-price ratio;
-Perfect after-sale service
