Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor

Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor

  • Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor
  • Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor
  • Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor
Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor
Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: Sumward
Chứng nhận: CE,ROHS, FCC,C-tick,BV,GMC
Model Number: LCD HD Monitor S1
Thanh toán:
Minimum Order Quantity: 2pcs
Giá bán: negotiation
Packaging Details: Inner 4CM PE foam,Middle export carton box,Outer export wooden box
Delivery Time: 7-25 days
Supply Ability: 3000PCS/month
Tiếp xúc
Chi tiết sản phẩm
Điểm nổi bật:

lcd cctv monitor

,

lcd computer monitor

Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor



Features



Dual infrared touch screen frame

USB or VGA interface available

Spill proof and Anti  Dust

True Flat designed to suit harsh environment

Best choice for space limited retail/hospitality settings

Easy for installation - One USB cable needed

Durable Die-casting Aluminum base design  for touch version



LCD Specification



LCD Size-21.6" , 16:9 LCD-Full New LCD screen from Samsung/LG/AU/CHIMEI

Screen Resolution:1920*1080

Colour-16.7m

Brightness-450cd

Contrast-300.1

Response Time-16-25ms

Interface-VGA (optional AV/TV/HDMI)

Power Supply built-in-AC 100V-240V



Screen Parameter



Transmittance

≥92%, 100% max (without Glass)

Outline Dimension

524(W±2.0)X343(D± 2.0)X8mm(H± 0.5)

Detection Form

Infrared rays interception detection form

Active Area

473mm(W)x296mm(D)

Resolution

1920(W)x1020(D)

Output Format

Coordinate Output

Optical Element Pace

5.97mm

Minimum Touch body Diameter

>5mm

Response Speed

16ms—25ms

Touch Accuracy

±1.5mm

Touch Limitation

No Limitation



Electricity



Scan Frequency

50Hz

USB1.1

Connector type

A type

Transmission speed

12Mbps

Signal

+5V, D-, D+, GND

Connector

USB A Port connector for cable

Temperature Range

Operating -40°C~70°C

Storage -40°C ~80°C

Humidity

Operating 0%-85%, non condensing

Storage 0%-95%, non condensing

Power Supply

DC 5V ± 5%, 270mA~290mA

Communication Interface

USB Port or RS232 (Plug & Play, No Drive)

Communication Distance

25Meter



Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor 0Industry CCTV LCD HD Monitor 22 inch AV / TV 50Hz , lcd computer monitor 1
