High Definition Digital Satellite Receiver Support AC DC Power With Alligator Clip Cable

Thông tin chi tiết sản phẩm:

Place of Origin:	China
Hàng hiệu:	ODM & OEM
Chứng nhận:	CE & RoHs
Model Number:	S-200

Thanh toán:

Minimum Order Quantity:	2000 PCS
Giá bán:	Negotiable
Packaging Details:	carton
Delivery Time:	25 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	50000 PCS Per Month

Tiếp xúc

Chi tiết sản phẩm

CPU:	ALI3329	SDRAM:	1X16MBit
Flash:	1MB	Tuner:	AV2028
Biss:	Support	TKGS:	Support
Điểm nổi bật:	wifi satellite receiver , 3g satellite receiver

ALI3329 Digital Satellite Receiver With crocodile Clip Cable Support AC DC Power In, BISS, TKGS, Dongle

Specifications:

TUNER : AV2028
Input Frequency : 950 to 2150 Mhz
Input Level : -65 to -25
LNB Supply : 13V / 18 V / OFF, max 400 mA
Demodulation Type: QPSK
Symbol Rate : 4 ~ < 45 MS/s

AUDIO/VIDEO PROCESSING

Sudio Standard : ISO/IEC 13818-3
Audio Channel : Mute, Left, Right and Stereo
Audio Decoding : MPEG-1 & MPEG-2 layer I and II
Video Standard : ISO/IEC 13818-2, MPEG-2 MP@ML
Aspect Ratio : 4:3
Video Resolution : 720 x 576 (PAL), 720 x 480 (NTSC)
Video Format : 4:3

Features:

1. Fully DVB-S/MPEG2 compliant
2. Supports DiSEqC 1.0/1.2
3. 0/22 Khz Tone
4. SCPC/MCPC Receivable from C/KU band satellite
5. 3 Operation Modes (Digital TV, Digital Radio, Favorite)
6. 950-2150 Mhz Input Frequency
7. Wide Symbol Rate 4-45 Mbps
8. MPEG-2 Main Profile at main level
9. Easy Graphic Menu Interface
10. 5 OSD Color Style
11. 16/256 colors on screen display (OSD) supported
12. PAL-NTSC auto-conversion
13. Up to 9 picture on screen
14. Software upgrade via RS-232 serial port
15. The Warranty of our dvb-s receiver is:12 monthes
16. Our dvb-s receiver has passed CE and ROHS
