Surface Mounted Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V

Surface Mounted Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V

  • Surface Mounted  Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V
Surface Mounted  Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V
Thông tin chi tiết sản phẩm:
Place of Origin: Jiangsu China
Hàng hiệu: MANORSHI
Chứng nhận: ISO, CE, ROHS
Model Number: MSES12A
Thanh toán:
Minimum Order Quantity: 500 PCS
Giá bán: USD0.1-0.2 Per Piece
Packaging Details: Export Standard Package
Delivery Time: 2-3 weeks
Payment Terms: L/C, T/T, Western Union, By Paypal
Supply Ability: 1000000PCS/MONTH
Tiếp xúc
Chi tiết sản phẩm
Product Name: Piezo Transducer Rated Voltage: 5V
Sound pressure: 85dB min. Current Consumption: 30mA
Điểm nổi bật:

electromagnetic buzzer

,

5v magnetic buzzer



Surface Mounted  Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V



 Quick Detail:

 1.Size:D12mm*H7.5mm





Specifications







   TYPE (UNIT) MSES12A23P01 MSES12A23P03 MSES12A23P05 MSES12A23P12
Min. Sound Output at 10cm (dB) 80 82 85 85
Rated Voltage VDC 1.5 3 5 12
Operating Voltage VDC 1.3~2 2~5 3~7 8~15
Resonant Frequency (Hz) 2300+/-400 2300+/-400 2300+/-300 2300+/-300
Max. Current Consumption (mA) 25 30 30 30
Operating Temperature -20 ~ +70 -20 ~ +70 -20??+70 -20 ~ +70
Storage Temperature -30 ~ +80 -30 ~ +80 -30 ~ +80 -30 ~ +80
Weight (g) 2 2 2 2



Frequency curve





Surface Mounted  Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V 0






 Drawing(mm)


Surface Mounted  Pin Electro Magnetic Buzzer DC Circuit 12 * 7.5mm 3V / 5V / 12V 1



 Active Magnetic buzzer work is direct current signal, usually labeled VDC, VDD. Because a simple oscillation circuit inside the buzzer, It can be a constant DC converted into a certain frequency of pulse signal, from beyond the alternating magnetic field, surface drive molybdenum slice vibration pronunciation. But in some active buzzer can also work under specific ac signal, It has high request on the voltage and frequency of the AC signal .
